Двигатель Запчасти для снегоходов Lynx (Bombardier) Rave 150 (1999)

Двигатель

Lynx (Bombardier) Rave 150

oem код

название

цена

10173

Engine

T36469A

Cylinder (incl. 2,20,72

Палец

Oil Drain Extension

Extension Cap

Шайба

Governor Rod

Governor Lever

Governor Lever Clamp

Screw, 8-32 X 3/8"

Extension Spring

19A

T34653

Extension Spring

19B

Extension Spring

Сальник

Подшипник

Blower Housing Baffle

25A

T35883

Baffle Extension

T650802

Screw, 1/4-20 X 5/8"

26A

Screw, 8-32 X 21/64"

Bearing Retainer

Lock Nut, 8-32

КОЛЕНЧАТЫЙ ВАЛ

Screw, 10-32 X 3/4"

Гровер

Lock Nut, 10-32

Стопорное кольцо

Piston, Pin & Ring

Piston, Pin & Ring

Piston, Pin & Ring

Piston & Pin AssвЂ™y Std. (incl. Ref 43)

T36071

Piston & Pin AssвЂ™y .010'вЂ™ (incl. Ref 43)

T36072

Piston & Pin AssвЂ™y .020'вЂ™ (incl. Ref 43)

Ring Set (std.)

Ring Set (.010")

Ring Set (.020")

Стопорное кольцо

Connecting Rod AssвЂ™y (incl. Ref. 46 & 49)

Connecting Rod Bolt

Valve Lifter

Oil Dipper

Camshaft (bcr)

Blower Housing Extension

T650760

Screw, 8-32 X 3/8"

T28545

Уплотнитель резиновый

Screw, 10-24 X 1/2"

Ground Terminal

Прокладка

Cylinder Cover. Includes Ref. 75...83

T27642

Oil Drain Plug

72A

T28582

Oil Drain Plug

T30200

Screw, 10-24 X 9/16,1

74A

Шайба

Сальник

Governor Shaft

Шайба

Gear Assy (includes Ref. 81)

T30588A

Governor Spool

T650488

Screw, 1/4-20 X 1-1/4"

Flywheel Key

Маховик

Belleville Washer

Flywheel Nut

100

T34443B

Solid State Ignition

101

T610118

Spark Plug Cover

102

T651024

Шпилька

103

T651007

Винт

110

T36681

Ground Wire

119

T36443

Прокладка головки блока цилиндров

120

T36441

Cylinder Head (includes Ref. 131)

125

T36471

Exhaust Valve Std. (includes Ref. 151)

125

T36472

Exhaust Valve (1/32'вЂ™ Incl. Ref 151)

126

T32644A

Intake Valve, Std. (includes Ref. 151)

126

T32645A

Intake Valve (1/32'вЂ™ Incl. Ref. 151)

127

T650691

Шайба

129

T650818

Screw, 5/16-18 X 1-1/2"

130

T6021A

Screw 5/16-18x1-1/2'вЂ™

130A

T650694A

Screw, 5/16-18 X 2"

135

T35395

Spark Plug (rj19lm)

150

T31672

Пружина клапана

151

T31673

Valve Spring Cap

169

T27234A

Valve Cover Gasket

170

T27666

Breather Body

171

T31410

Breather Element

172

T34146

Крышка клапанная

173

T35350

Breather Tube

174

T65078

Screw, 10-24 X 9/16"

178

T650783

Nut & Lock Washer

181

T650870

Винт

182

T6201

Screw, 1/4-28 X 7/8"

183

T34583A

Choke Bracket

184

T26756

Прокладка

185

T33666

Впускная труба

186

T32698

Governor Link

200

T34652A

Control Bracket (incl. Ref. 203...211)

203

T31342

Пружина сжатия

204

T651029

Screw, 5-40 X 7/16"

209

T650139

Screw, 8-32 X 1/2"

209A

T30322

Lock Nut

209B

T650688

Screw, 10-32 X 1"

210

T27793

Conduit Clip

211

T28942

Screw, 10-32 X 3/8"

222

T28820

Screw, 10-32x1/2'вЂ™

223

T650664

Винт

223A

T30646

Винт

224

T33673A

Intake Pipe Gasket

260

T35585

Blower Housing

262

T650737

Screw, 1/4-20 X 1/2"

267

T34212

Hold Down Bracket

268

T30200

Screw, 10-24 X 9/16"

274

T33670A

Прокладка

285

T36467A

Starter Cup

287

T650926

Screw, 8-32 X 21/64"

290

T30962

Трубопровод

291

T29774

Трубопровод

292

T26460

Fuel Line Clamp

295

T35857

Fuel Shut-off Valve

298

40829

Винт

300

T35584

Fuel Tank And Cap

301

T36246

Fuel Cap

302

5341202

Крышка

311

T27625

Oil Fill Plug

313

T34080

Проставка

313A

T35189

Проставка

314

T650873

Screw, 1/4-20 X 3/4"

315

T611095

Alternator Coil (incl. Ref. 322 & 323)

322

T610823

Connector Body

323

T610822

Терминал

324

T33177

Termninal

325

T27275

Wire Clip

342

T650751

Screw, 1/4-20 X 7/16"

350

T570682

Primer AssвЂ™y.

351

T32180C

Primer Line (12.00")

370A

T36261

Lubrication Decal

370C

T36501

Primer Decal

370K

T36695

Starter Decal

380

T632113A

Carburetor (includes Ref. 184)

390

T590743

Rewind Starter

400

T36444

Комплет прокладок

403

5440236

Nut Plate

404

20014

Гровер

405

40828

Allen Screw M8x35

406

5341827

Крышка

407

5441863

Держатель

420

32666

4-stroke Engine Oil
