Подвеска-задний амортизатор

Cam-am 003 - Maverick MAX Turbo RR - XRS - CE
Cam-am
#oem кодцена
130a
706002257
Rear Adjustable Shock Absorber.
130aa
715900337
Spherical Bearing.
130ab
715900482
Bearing.
130ac
715900338
O-Ring Bushing.
130ad
715900480
Circlip.
130ae
715900481
Reducer.
130af
715900521
Screw M6 X 35.
130ag
715900522
R?servoir Clamp.
130aq
706203583
Connector Support.
130b
706003792
Deep Black, Compression Spring.
130c
706002674
Rear Spring.
130d
706202215
Protector.
130e
250200025
Washer M5.
130f
210251150
Hex. Flanged Screw M5 X 11.
130j
205551060
Socket Head Screw M5 X 10.
135a
706002257
Rear Adjustable Shock Absorber.
135aa
715900337
Spherical Bearing.
135ab
715900482
Bearing.
135ac
715900338
O-Ring Bushing.
135ad
715900480
Circlip.
135ae
715900481
Reducer.
135af
715900521
Screw M6 X 35.
135ag
715900522
R?servoir Clamp.
135aq
706203583
Connector Support.
135b
706003792
Deep Black, Compression Spring.
135c
706002674
Rear Spring.
135d
706202215
Protector.
135e
250200025
Washer M5.
135f
210251150
Hex. Flanged Screw M5 X 11.
135j
205551060
Socket Head Screw M5 X 10.
140
250000857
Screw Flange M12 X 60.
145
233221466
Elastic Flange Nut M12.
150
250000858
Hexagonal Flanged Screw M12 X 70.
