01- engine - rewind starter - 600 carb

Ski-Doo (Bombardier) RENEGADE 600 CARB - North America

01- engine - rewind starter - 600 carb

#

oem код

название

цена

1

Flange Connector.

Flange Connector.

10

КОЛЬЦО

КОЛЬЦО

11

Lock Ring.

Lock Ring.

12

Locking Element.

Locking Element.

13

Hex. Collar Screw.

Hex. Collar Screw.

2

Socket Head Screw M6 X 16.

Socket Head Screw M6 X 16.

3b

Starter Housing.

Starter Housing.

4

Rewind Spring.

Rewind Spring.

5

Rope Sheave.

Rope Sheave.

6

Starter Rope, Meter.

Starter Rope, Meter.

7

Pawl.

Pawl.

8

Pawl Lock.

Pawl Lock.

9

Stage Sleeve.

Stage Sleeve.
