Clamp bracket transom(x) (df200z e03)
Clamp bracket transom(x) (df200z e03)

Clamp bracket transom(x) (df200z e03)

Suzuki Marine DF200/DF225/DF250

Clamp bracket transom(x) (df200z e03)

#

oem код

название

цена

3

Plate, Clamp Bra

Plate, Clamp Bra

4

Plate, Clamp Bra

Plate, Clamp Bra

5

Screw 6x10 (sus

Screw 6x10 (sus

6

Shaft, Clamp Bra

Shaft, Clamp Bra

7

Washer, Clamp Br

Washer, Clamp Br

8

Гайка

Гайка

9

Крышка

Крышка

11

Гайка

Гайка

12

Washer(13.2x45x

Washer(13.2x45x

13

Washer(13.2x26x

Washer(13.2x26x

14

Пластина

Пластина

15

Anode Set

Anode Set

16

Болт

Болт

17

Pin, Tilt Lock

Pin, Tilt Lock

18

Nut 14mm

Nut 14mm

19

Cam Assy, Tilt L

Cam Assy, Tilt L

20

Holder, Tilt Lim

Holder, Tilt Lim

21

Bolt, Tilt Limit

Bolt, Tilt Limit

22

Magniesium Anod (opt)

Magniesium Anod (opt)

23

Cover, Tilt Limi

Cover, Tilt Limi

24

Lead, Clamp To S

Lead, Clamp To S

25

Screw 6x10 (sus

Screw 6x10 (sus

1-1

41111-93J14-0EP

Bracket, Clamp S

Bracket, Clamp S

1-2

41111-93J14-Y5S

Bracket, Clamp S

Bracket, Clamp S

2-1

41121-93J06-0EP

Bracket, Clamp P

Bracket, Clamp P

2-2

41121-93J06-Y5S

Bracket, Clamp P

Bracket, Clamp P

10-1

Bolt, Transom (opt)

Bolt, Transom (opt)

10-2

Bolt, Transom

Bolt, Transom

10-3

Bolt, 115mm Long (opt)

Bolt, 115mm Long (opt)
