Swivel bracket (df150tg e03)
Swivel bracket (df150tg e03)

Swivel bracket (df150tg e03)

Suzuki Marine DF150/DF175 T, Z, ST,TG,ZG,

oem код

название

цена

22511-99011

Ниппель

36894-87D00

Lead, Clamp To S

3-1

43111-96J00-0EP

Bracket, Swivel( (w/transom(l))

3-2

43111-96J00-Y5S

Bracket, Swivel (w/transom(l))

3-3

43111-96J10-0EP

Bracket, Swivel( (w/transom(x))

3-4

43111-96J10-Y5S

Bracket, Swivel (w/transom(x))

43211-93J00

Bushing, Swivel

43711-97E01

Bush, Steering

6-1

43750-96J02-0EP

Bracket, Steerin (w/transom(l))

6-2

43750-96J02-Y5S

Bracket, Steerin (w/transom(l))

6-3

43750-96J12-0EP

Bracket, Steerin (w/transom(x))

6-4

43750-96J12-Y5S

Bracket, Steerin (w/transom(x))

09125-06063

Screw 6x10 (sus

09160-39001

Washer 39.5x64x

09181-39001

Регулировочная прокладка

СТОПОРНОЕ КОЛЬЦО

Шайба

Oil Seal 39x51x

Anode, Protectio

Bolt, Protection

Lever, Tilt Lock

Lever, Tilt Lock

Bush, Tilt Stop

Link, Tilt Lock

Bracket, Tilt Lo

Screw 6x10 (sus

Гайка

Шайба

Штифт

Пружина

Spring, Tilt Loc

Lead, Clamp To S

Screw 6x10 (sus
