Drive Shaft Housing (DF150Z E03)
Drive Shaft Housing (DF150Z E03)

Drive Shaft Housing (DF150Z E03)

Suzuki Marine DF 175ZGL

Drive Shaft Housing (DF150Z E03)

#

oem код

название

цена

1-2

52111-96J10-Y5S

HOUSING, DRIVE SHAFT (X) (WHITE)

HOUSING, DRIVE SHAFT (X) (WHITE)

1-1

52111-96J10-0EP

HOUSING, DRIVE SHAFT (X) (BLACK)

HOUSING, DRIVE SHAFT (X) (BLACK)

2

BOLT (10X44)

BOLT (10X44)

3

PIN (8X12)

PIN (8X12)

4

BUSH, DRIVE SHAFT

BUSH, DRIVE SHAFT

5

RING

RING

6

LEAD (SWIVEL TO HSG)

LEAD (SWIVEL TO HSG)

7

SCREW (6X10)

SCREW (6X10)

8

MOUNT, LOWER THRUST

MOUNT, LOWER THRUST

9

MOUNT, LOWER

MOUNT, LOWER

10-1

54211-96J01-0EP

BRACKET, LOWER MOUNT (BLACK)

BRACKET, LOWER MOUNT (BLACK)

10-2

54211-96J01-Y5S

BRACKET, LOWER MOUNT (WHITE)

BRACKET, LOWER MOUNT (WHITE)

11

COVER, LOWER MOUNT

COVER, LOWER MOUNT

12

BOLT (14X220)

BOLT (14X220)

13

BOLT (10X35)

BOLT (10X35)

14

BOLT (10X50)

BOLT (10X50)

15

WASHER (16X32X3)

WASHER (16X32X3)

16

WASHER (16X32X3)

WASHER (16X32X3)

17

CLAMP (L:100) *{UP TO VIN.510048}*

CLAMP (L:100) *{UP TO VIN.510048}*

18

MOUNT, LOWER SIDE

MOUNT, LOWER SIDE
