Thermostat (DF40A E03)
Thermostat (DF40A E03)

Thermostat (DF40A E03)

Suzuki Marine DF 40ATLW2

Thermostat (DF40A E03)

#

oem код

название

цена

1-1

17611-90J00-YAY

COVER, WATER PRESS VALVE (BLACK)

COVER, WATER PRESS VALVE (BLACK)

1-2

17611-90J00-Y5S

COVER, WATER PRESS VALVE (WHITE)

COVER, WATER PRESS VALVE (WHITE)

2

VALVE, WATER PRESSURE

VALVE, WATER PRESSURE

3

BOLT (6X25)

BOLT (6X25)

4

O RING (D:3.1,ID:26.4)

O RING (D:3.1,ID:26.4)

5

THERMOSTAT (60 C)

THERMOSTAT (60 C)

6

COVER, THERMOSTAT

COVER, THERMOSTAT

7

BOLT

BOLT

8

HOSE, WATER RETURN

HOSE, WATER RETURN

9

CLIP

CLIP

10

PROTECTOR, WATER HOSE *{L:320->50}*

PROTECTOR, WATER HOSE *{L:320->50}*

11

HOSE (SEPARATOR TO INSP)

HOSE (SEPARATOR TO INSP)

12

09352-50903-600

HOSE (5X9X600) *{L:600->500}*

HOSE (5X9X600) *{L:600->500}*

13

09359-50901-980

HOSE *{L:980->250}*

HOSE *{L:980->250}*

14

CLIP

CLIP

15

CLIP

CLIP

16

CLAMP

CLAMP
