ВОДЯНОЙ НАСОС

Suzuki Marine DF 50ATL
Suzuki Marine
#oem кодцена
1
17410-88L00
CASE, WATER PUMP
2
17413-95J00
SLEEVE, WATER PUMP CASE
3
17416-95J00
SEALING, WATER PUMP CASE
4
17564-88L00
BUSH, WATER PUMP CASE
5
29141-93J00
NUT
6
29162-93J00
WASHER, LOCK
7
09108-06143
BOLT, PUMP CASE STUD (L:45)
8
09108-06144
BOLT, PUMP CASE STUD (L:31)
9
17461-96312
IMPELLER, WATER PUMP
10
17471-95J01
PANEL, PUMP CASE UNDER
11
17472-96303
GASKET, PUMP CASE UNDER
12-1
17560-88L10
TUBE, WATER (L)
12-2
17560-88L20
TUBE, WATER (X)
13
17562-87L00
GROMMET, WATER TUBE UPPER
14
17562-87L00
GROMMET, WATER TUBE LOWER
15
09116-06094
BOLT, WATER TUBE
16
17631-96320
FILTER, WATER
17
03142-04309
SCREW
18-1
17635-87E00
FILTER, SUB WATER
18-2
17635-87E10
PLATE, GEAR CASE *{OPT}*
19
09125-05046
SCREW
20
09420-04006
KEY
21
17400-88L00
WATER PUMP REPAIR KIT *{OPT INC.NO.2,3,9~11,20}*
