КАРТЕР КОРОБКИ ПЕРЕДАЧ
КАРТЕР КОРОБКИ ПЕРЕДАЧ

КАРТЕР КОРОБКИ ПЕРЕДАЧ

Tohatsu MFS4C

КАРТЕР КОРОБКИ ПЕРЕДАЧ

#

oem код

название

цена

1

GEAR CASE ASSY

GEAR CASE ASSY

2

NEEDLE BEARING 14-20-12

NEEDLE BEARING 14-20-12

3

WATER PLUG

WATER PLUG

4

GASKET 8.1-15-1

GASKET 8.1-15-1

5

ANODE

ANODE

6

BOLT

BOLT

7

BALL BEARING 6004

BALL BEARING 6004

8

PROPELLER SHAFT HOUSING ASSY

PROPELLER SHAFT HOUSING ASSY

9

PROPELLER SHAFT HOUSING

PROPELLER SHAFT HOUSING

10

OIL SEAL 15-28-10

OIL SEAL 15-28-10

11

O-RING 3.2-47

O-RING 3.2-47

12

BALL BEARING 6002

BALL BEARING 6002

13

BEVEL GEAR A

BEVEL GEAR A

14

BEVEL GEAR B

BEVEL GEAR B

15

BEVEL GEAR C

BEVEL GEAR C

16

WASHER 15.2-19-1.9

WASHER 15.2-19-1.9

17

SHIM 21-28-.01

SHIM 21-28-.01

18

PROPELLER SHAFT

PROPELLER SHAFT

19

CLUTCH

CLUTCH

20

SPRING PIN 3.5-28

SPRING PIN 3.5-28

21

CLUTCH SPRING

CLUTCH SPRING

22

CLUTCH SPRING RETAINER

CLUTCH SPRING RETAINER

23

CLUTCH PUSH ROD

CLUTCH PUSH ROD

24

WATER STRAINER

WATER STRAINER

25

SCREW

SCREW

26

LOWER WATER PIPE

LOWER WATER PIPE

27

LOWER WATER PIPE SEAL

LOWER WATER PIPE SEAL

28

WATER PUMP IMPELLER

WATER PUMP IMPELLER

29

WATER PUMP IMPELLER KEY

WATER PUMP IMPELLER KEY

30

PUMP CASE (UPPER)

PUMP CASE (UPPER)

31

PUMP CASE LINER

PUMP CASE LINER

32

WATER PUMP GUIDE PLATE

WATER PUMP GUIDE PLATE

33

PUMP CASE GASKET (UPPER)

PUMP CASE GASKET (UPPER)

34

PUMP GUIDE PLATE GASKET

PUMP GUIDE PLATE GASKET

35

BOLT

BOLT

36

WASHER

WASHER

37

PUMP CASE (LOWER)

PUMP CASE (LOWER)

38

OIL SEAL 10-24-8

OIL SEAL 10-24-8

39

SHIM 26.5 - 34.8 - 0.1

SHIM 26.5 - 34.8 - 0.1

40

PUMP CASE GASKET (LOWER)

PUMP CASE GASKET (LOWER)

41

BOLT

BOLT

42

WATER PIPE SEAL (LOWER)

WATER PIPE SEAL (LOWER)

43

DRIVE SHAFT S

DRIVE SHAFT S

44

BALL BEARING 6300

BALL BEARING 6300

45

CLUTCH CAM

CLUTCH CAM

46

SPRING PIN 3-10

SPRING PIN 3-10

47

CAM ROD (S)

CAM ROD (S)

48

CAM ROD BUSHING

CAM ROD BUSHING

49

O-RING 2.5-4.9

O-RING 2.5-4.9

50

O-RING 2.4-15.4

O-RING 2.4-15.4

51

STOPPER

STOPPER

52

GROMMET

GROMMET

53

BOLT

BOLT

54

WASHER

WASHER

55

BOLT

BOLT

56

WASHER

WASHER

57

BOLT (OR 910113-5616)

BOLT (OR 910113-5616)

58

WATER PIPE S

WATER PIPE S

59

WATER PIPE GROMMER (UPPER)

WATER PIPE GROMMER (UPPER)

60

PROPELLER (8.375d X 6p) High Thrust

PROPELLER (8.375d X 6p) High Thrust

61

PROPELLER HARDWARE KIT

PROPELLER HARDWARE KIT

62

PROPELLER THRUST HOLDER

PROPELLER THRUST HOLDER

63

WASHER 10.5-28-2

WASHER 10.5-28-2

64

PROPELLER NUT

PROPELLER NUT

65

SPLIT PIN 3-18

SPLIT PIN 3-18
