Side leg shield (model k7)

Suzuki AN650 (Burgman)

Side leg shield (model k7)

#

oem код

название

цена

1-1

48171-10G00-YC3

Shield, Leg Side Rh (white) (an650)

Shield, Leg Side Rh (white) (an650)

1-2

48171-10G00-YHF

Shield, Leg Side (an650 E3, E33)

Shield, Leg Side (an650 E3, E33)

1-3

48171-10G00-YHG

Shield, Leg Side Rh (gray) (an650a E28)

Shield, Leg Side Rh (gray) (an650a E28)

1-4

48171-10G00-YHL

Shield, Leg Side Rh (red) (an650a E3,e33)

Shield, Leg Side Rh (red) (an650a E3,e33)

2

Cushion, Rh ()

Cushion, Rh ()

3-1

48181-10G20-YC3

Shield, Leg Side Lh (white) (an650)

Shield, Leg Side Lh (white) (an650)

3-2

48181-10G20-YHF

Shield, Leg Side Lh (gray) (an650 E3,e33)

Shield, Leg Side Lh (gray) (an650 E3,e33)

3-3

48181-10G20-YHG

Shield, Leg Side Lh (gray) (an650a E28)

Shield, Leg Side Lh (gray) (an650a E28)

3-4

48181-10G20-YHL

Shield, Leg Side Lh (red) (an650a E3,e33)

Shield, Leg Side Lh (red) (an650a E3,e33)

4

Cover, Lh ()

Cover, Lh ()

5

Cushion, Lh ()

Cushion, Lh ()

6

Clip ()

Clip ()

7

Screw, Cover ()

Screw, Cover ()

8

Гайка

Гайка

9

09409-08308-5ES

Clip (black) ()

Clip (black) ()
