Side cover (vzr1800k9/nk9)

Suzuki VZR1800,N,Z Boulevard M109R

Side cover (vzr1800k9/nk9)

#

oem код

название

цена

1-1

47110-48G00-YAY

Cover, Frame Rh (black)

Cover, Frame Rh (black)

1-2

47110-48G00-YMD

Cover, Side, R(si

Cover, Side, R(si

1-3

47110-48G00-YMK

Cover, Side, R(re (vzr1800)

Cover, Side, R(re (vzr1800)

2-1

47210-48G00-YAY

Cover, Frame Lh (black)

Cover, Frame Lh (black)

2-2

47210-48G00-YMD

Cover, Side, L(si

Cover, Side, L(si

2-3

47210-48G00-YMK

Cover, Side, L(re (vzr1800)

Cover, Side, L(re (vzr1800)

3

.emblem

.emblem

4

.grommet

.grommet

5

Винт

Винт

6

Cover, Side Lower Rh

Cover, Side Lower Rh

7

Cover, Side Lower Lh

Cover, Side Lower Lh

8

Screw, Brace

Screw, Brace

9

Шайба

Шайба

10

Cushion, Lower

Cushion, Lower

11

Винт

Винт

12

Проставка

Проставка

13

.cushion, 8.5x20x8

.cushion, 8.5x20x8

14

Cover, Lower Rh

Cover, Lower Rh

15

Cover, Lower Lh

Cover, Lower Lh

17

Bracket Comp, Lo (not Illustrated)

Bracket Comp, Lo (not Illustrated)
