Side cover (vzr1800zk7/zk8)

Suzuki VZR1800 Boulevard M109R
Suzuki
#oem кодцена
1-1
47110-48G50-YKY
Cover Comp, Side (model K7)
1-2
47110-48G50-YMF
Cover Comp, Side (model K8)
2-1
47210-48G50-YKY
Cover Comp, Side (model K7)
2-2
47210-48G50-YMF
Cover Comp, Side (model K8)
3
68131-48G00
.emblem ()
4
09320-08028
.grommet ()
5
03541-0516A
Винт
6
47121-48G00
Cover, Side Lower Rh ()
7
47221-48G00
Cover, Side Lower Lh ()
8
09139-06126
Screw, Brace ()
9
09160-10123
Шайба
10
09320-09501
Cushion, Lower ()
11
09139-06029
Screw, Front ()
12
09180-06319
Spacer ()
13
09320-08021
.cushion, 8.5x20x8 ()
14
47130-48G00
Cover, Lower Rh ()
15
47231-48G10
Cover, Lower Lh ()
17
47250-48G00
Bracket Comp, Lo (not Illustrated)
