Обтекатель , крылья

KTM 1190 RC 8 ORANGE 08 / PS 09 CHASSIS

Обтекатель , крылья

#

oem код

название

цена

1

Fairing Screen High 08

Fairing Screen High 08

2

Fr.fair.up.part L/s Or.br. Rc8

Fr.fair.up.part L/s Or.br. Rc8

3

Fr.fair.up.part R/s Or.br. Rc8

Fr.fair.up.part R/s Or.br. Rc8

4

Fr.fair.lo.part L/s Or.ma. Rc8

Fr.fair.lo.part L/s Or.ma. Rc8

5

Fr.fair.lo.part R/s Or.ma. Rc8

Fr.fair.lo.part R/s Or.ma. Rc8

6

Exit-air Shaft L/s Bl.matt Rc8

Exit-air Shaft L/s Bl.matt Rc8

7

Exit-air Shaft R/s Bl.matt Rc8

Exit-air Shaft R/s Bl.matt Rc8

8

Cooler Fairing L/s Or. Br. Rc8

Cooler Fairing L/s Or. Br. Rc8

9

Cooler Fairing R/s Or. Br. Rc8

Cooler Fairing R/s Or. Br. Rc8

10

Fresh-air Shaft L/s Bl. Ma. 08

Fresh-air Shaft L/s Bl. Ma. 08

11

Fresh-air Shaft R/s Bl. Ma. 08

Fresh-air Shaft R/s Bl. Ma. 08

12

Up. Fresh-air Shaft Bl. Ma. 08

Up. Fresh-air Shaft Bl. Ma. 08

13

Front Fender Or. Matt 08

Front Fender Or. Matt 08

14

Side Cover L/s Bl. Br. Rc8

Side Cover L/s Bl. Br. Rc8

15

Side Cover R/s Bl. Gl. Rc8

Side Cover R/s Bl. Gl. Rc8

16

Rear Fairing L/s Bl. Br. Rc8

Rear Fairing L/s Bl. Br. Rc8

17

Rear Fairing R/s Bl. Br. Rc8

Rear Fairing R/s Bl. Br. Rc8

18

Rear Light Adapter R/s

Rear Light Adapter R/s

19

Rear Light Adapter L/s

Rear Light Adapter L/s

20

Upper Rear End Panel

Upper Rear End Panel

21

License Plate Bracket Lo. Part

License Plate Bracket Lo. Part

22

License Plate Bracket Up. Part

License Plate Bracket Up. Part

23

Шайба резиновая

Шайба резиновая

24

Винт м6х16

Винт м6х16

27

Blind Plug-in Nut M5 Wn 16a 03

Blind Plug-in Nut M5 Wn 16a 03

28

Hh Collar Screw M5x16 Tx30

Hh Collar Screw M5x16 Tx30

29

Spread Rivet Cpl. 6, 2mm

Spread Rivet Cpl. 6, 2mm

30

Винт М6х13

Винт М6х13

31

Screw Torx M5x10 05

Screw Torx M5x10 05

32

Washer Rear-ut D=14mm

Washer Rear-ut D=14mm

33

Rubber Sleeve D=8mm Open

Rubber Sleeve D=8mm Open

34

Винт M8x20 Tx40

Винт M8x20 Tx40

35

Washer Mount. Rear Fairing

Washer Mount. Rear Fairing

36

Болт 50x16 1451

Болт 50x16 1451

37

Rubber Sleeve 10x14x20 08

Rubber Sleeve 10x14x20 08

38

Passengers Seat Plate Kit

Passengers Seat Plate Kit

39

Screw For Plastic K40x16 T20

Screw For Plastic K40x16 T20

40

Воротник Винт M6x25 Tx30

Воротник Винт M6x25 Tx30

41

Collar Bush. 6, 2x10x21x14mm 08

Collar Bush. 6, 2x10x21x14mm 08

42

Винт М6х20

Винт М6х20

43

Bushing License Plate Bracket

Bushing License Plate Bracket

44

Hh Collar Screw M5x20 Tx30

Hh Collar Screw M5x20 Tx30

45

Plain Washer Pa 9, 5x14x2

Plain Washer Pa 9, 5x14x2

50

Licence Fitting 06

Licence Fitting 06

51

Hh Collar Screw M6x15 Tx30

Hh Collar Screw M6x15 Tx30

52

Washer Din9021-a 6, 4

Washer Din9021-a 6, 4

53

Self Lock. Nut Din0985-m 6

Self Lock. Nut Din0985-m 6

54

Винт с полупотайной головкой Din0966-м 5х16

Винт с полупотайной головкой Din0966-м 5х16

55

Шайба 6мм

Шайба 6мм

56

Шайба Din0125-в 5, 3

Шайба Din0125-в 5, 3

57

Самоконтрящаяся Гайка 0985-м DIN 5

Самоконтрящаяся Гайка 0985-м DIN 5

58

Reflector Red Lc4 '98

Reflector Red Lc4 '98

59

Bracket For Reflector

Bracket For Reflector

62

Кронштейн Бокового Отражателя 06

Кронштейн Бокового Отражателя 06

63

Боковой Отражатель Красный Задний

Боковой Отражатель Красный Задний

64

Side Reflector Yellow 03

Side Reflector Yellow 03

65

Bracket F. Side Reflector L/s

Bracket F. Side Reflector L/s

66

Bracket F. Side Reflector R/s

Bracket F. Side Reflector R/s
