Swingarm 450

KTM 450 SUPERMOTO FACTORY REPLICA
KTM
#oem кодцена
1
59204030044
Swingarm Cpl."n4" 450sm F.r.04
3
50304066100
Chain Guard 05
4
72210079000
Шайба
5
0015060103
Hh Collar Screw M 6x10 Ws=8
6
54611076100
Retain.clamp For Brake Hose'96
7
0009050103
Special Screw M 5, 0x10
8
54804034000
Bucket F. Shaft Seal Ring 03
9
0760253270
Shaft Seal Ring 25x32x7
10
59404032000
Bearing Sleeve 17x22x38, 7 03
11
59004031100
Needle Bearing Hk2212v
12
54603036000
Stop Disk 22, 2x31, 7x1
13
54607066100
Chain Guide Rear '94
14
56509064100
Self Locking Nut M6 10.9
15
0014060153
Hh Collar Screw M 6x15 Ws=8
16
0015060403
Hh Collar Screw M 6x40 Ws=8
18
50304090044
Pivot Bearing+bushes Pds '99
19
50329000044
Tool Bearing Mounting Pds
25
77304037000
Swingarm Bolt M16x1, 5 07
26
54804038000
Self Lock.nut M16x1, 5 Ws=19 03
36
59204066000
Chain Guard Bottom Sm 2004
37
57304067000
Chain Guard Top Sm 2003
11
59004031200
Needle Bush Hk2212v
16
0025060406
Hh Collar Screw M6x40 Tx30
