Tank,sitzbank,verkleidung tank,seat,cover 400/620 98

KTM 400/620 R/XC e CHASSIS
KTM
#oem кодцена
5
58307005100
Fuel Cock Mikuni Ck-84 '96
6
58307106100
Gasket Fuel Cock Mikuni
8
56007008144
Tank Cap Cpl. Large
9
56007009100
Gasket For Tank Cap
10
0125060003
Washer Din0125-a 6, 4
11
58007044000
Oval Head Screw M6x15
12
0015060303
Hh Collar Screw M 6x30 Sw=8
13
58307013400
Fuel Tank 11, 3 Liter '97
14
58307014000
Special Nut M8
17
58031005000
Хомут 12мм
18
0017060203
Ejot Pt Screw K60x20 Ws=6
19
0797050003
Tooth Lock Wash. Din6797-j 5, 3
20
0014060203
Hh Collar Screw M 6x20 Ws=8
21
0024060106
Hh Collar Screw M6x10 Tx30
22
50235033300
Snap-nut Holder M6 Kp142
23
58307113250
Tank Bushing Cpl. 12 X 34 X 25
24
0015060253
Hh Collar Screw M 6x25 Ws=8
28
58335028000
Spoiler White L/s '93
40
58307240900
Seat Grey/black Rxc-e '98
41
58307240950
Seat Cover Grey/black Rxc-e'
42
58307019000
Washer 10, 5 X 25 X 1, 5
43
50233041000
Pair Of Washers M 6 Nordlock
44
0015060123
Hh Collar Screw M 6x12 Ws=8
48
54603048100
Range Change Metal Nut M6
50
58308041050
Heat Protector
52
51005067100
Insolate Washer 12x28x3
67
0021080003
Washer Din9021-a 8, 4
68
0934080003
Hexagon Nut Din0934-m 8
81
58308041000
Side Cover White L/s '93
