ТЕРМОСТАТ

Johnson J140CX4STS
Johnson
#oem кодцена
1
5033644
Hose, Water Return
2
5033718
Крышка
3
5033720
Valve Comp
4
5033721
Thermostat, 60deg C
4
5033722
Thermostat (c 71) (optional )
5
5036683
Крышка термостата
6
5033724
3 Way, Water Hose
7
5030391
Болт 6x25
8
5030541
Oring
9
5033621
Hose, 11x15x600 (cut To Length From P/n 5033621 )
10
5030122
Hose (cut To Length From P/n 5030122 )
21
5030127
Joint, 3 Way
22
5030577
Зажим
23
5033626
Зажим
24
5034144
Зажим
25
5033629
Clip, D23
26
5033630
Зажим
27
5030990
Болт
1
5033644
Hose, Water Return
3
5033720
Valve Comp
4
5033721
Thermostat, 60deg C
4
5033722
Thermostat (c 71) (optional )
5
5036683
Крышка термостата
6
5033724
3 Way, Water Hose
7
5030391
Болт 6x25
8
5030541
Oring
9
5033621
Hose, 11x15x600 (cut To Length From P/n 5033621 )
10
5030122
Hose (cut To Length From P/n 5030122 )
11
5030122
Hose (cut To Length From P/n 5030122 )
12
5030122
Hose (cut To Length From P/n 5030122 )
13
5030122
Hose (cut To Length From P/n 5030122 )
14
5030122
Hose (cut To Length From P/n 5030122 )
15
5030122
Hose (cut To Length From P/n 5030122 )
16
5030122
Hose (cut To Length From P/n 5030122 )
17
5030122
Hose (cut To Length From P/n 5030122 )
18
5030122
Hose (cut To Length From P/n 5030122 )
19
5030122
Hose (cut To Length From P/n 5030122 )
20
5030122
Hose (cut To Length From P/n 5030122 )
21
5030127
Joint, 3 Way
22
5030577
Зажим
23
5033626
Зажим
24
5034144
Зажим
25
5033629
Clip, D23
26
5033630
Зажим
27
5030990
Болт
