Электрика

Ski-Doo (Bombardier) Formula Z 583
Ski-Doo (Bombardier)
#oem кодцена
515175336
Спидометр
515175546
Regu.tension As*regulator-volt Formula 500 Deluxe. Formula 583 Deluxe.
210261680
Screw-forming Hex.hd.fl.gm6174m Formula 500 Deluxe. Formula 583 Deluxe.
1
410301201
Batterie M2218y*battery (dry) Includes 1 - 5. Formula 500 Deluxe. Formula 583 Deluxe.
1
410107300
Выключатель обогрева рукояток
2
515175728
Контрольная лампа
2
410300800
Bouchon Batt. *cap-battery Formula 500 Deluxe. Formula 583 Deluxe.
3
515175726
Контрольная лампа
3
207161644
Screw-hex.cap Din.933 Formula 500 Deluxe. Formula 583 Deluxe.
4
391302100
Washer-flat Yic Formula 500 Deluxe. Formula 583 Deluxe.
4
517258500
Шайба
5
232061414
Nut-hexagonal Din.934 Formula 500 Deluxe. Formula 583 Deluxe.
5
572022300
Corr.vitesse *drive-angle 1994 -
6
414991700
Заготовка ключа
6
570022000
Couvercle Batt.*cover-battery Formula 500 Deluxe. Formula 583 Deluxe.
7
570013700
Пыльник выключателя
7
517286000
Laniere Soudee *strip-steel W.paint Formula 500 Deluxe. Formula 583 Deluxe.
8
410112100
Гайка лицевая
8
517286200
Siege Batterie *seat-battery Formula 500 Deluxe. Formula 583 Deluxe.
9
207152044
Screw-hex.cap Din.933 Formula 500 Deluxe. Formula 583 Deluxe.
9
410113602
Замок зажигания
11
410109700
Lampe Temoin *lamp-pilot Formula 500.
12
570151000
Capuchon Prot. *cap-protection Formula 500 Deluxe. Formula 583 Deluxe.
12
515176463
Capuchon Ass. *cap-assy.
13
515145900
Ecrou Inter. *nut-switch
13
234151401
Washer-lock Helical Din.127b Formula 500 Deluxe. Formula 583 Deluxe.
14
390402200
Rivet-pop 3/16 *rivet-pop 3/16 Formula 500 Deluxe. Formula 583 Deluxe.
14
570151100
Cap.plongeur *cap-plunger
15
517286100
Laniere Peinte *strip-steel Paint Formula 500 Deluxe. Formula 583 Deluxe.
15
515175341
Compte-tours *tachometer
16
394001900
Washer-lock Ext.tooth Formula 500 Deluxe. Formula 583 Deluxe.
16
515176525
Interruteur *brake Switch
17
293800005
Loctite 271 *loctite-271 Formula 500 Deluxe. Formula 583 Deluxe.
17
605152889
Спидометр
18
415079900
Gaine *protector Tube Formula 500 Deluxe. Formula 583 Deluxe.
18
414806700
Шайба
19
293750008
Tie Rap 350mm *tie-rap 350mm Formula 500 Deluxe. Formula 583 Deluxe.
19
410504200
Лампочка спидометра
20
414807100
Joint Torique *packing
21
515163800
Regu.tension As*regu-volt.assy Formula 500. Formula Z 583.
22
414806500
Support Boitier*holder-case
23
414761400
Cable Vitesse *cable-speedo
24
732600016
Screw-forming Hex.hd.fl.gm6174m Formula 500. Formula Z 583.
25
517225900
Шайба
26
515175281
Крышка кнопки
27
517168600
Пружина
28
409210000
Электрическая клемма "папа"
29
409204500
Электрическая клемма "папа"
31
409204200
Logement Male *housing-male Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
32
515175342
Indicateur Temp*gauge-temp. Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
33
415114700
Capt.niv.ess. *sensor-fuel Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
34
414806900
Гайка
35
391301700
Rondelle *washer Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
36
414227300
Пружина
37
414176000
Хомут открывающийся
38
232551414
Nut-stop Elastic Din.985 Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
39
414833600
Ecrou Gauge *nut-gauge Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
40
414833700
Washer-lock Gauge Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
41
415018200
Крепёж
42
414806600
Support Boitier*holder-case Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
43
517258600
Rondelle Formee*washer Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
44
415100700
Vis Ajust. Ass.*screw-adjust.a Includes 44 - 46.
45
732603004
Screw-plastite Hex.48-2 7mm Af
46
572106600
Manette *handle
47
572078600
Ecrou De Phare *nut-lamp
48
207151644
Винт
50
517218500
Support Phare *support-lamp
51
233251414
Гайка
52
410608200
Butoir Caout. *bumper-rubber
53
410609100
Phare *headlamp Includes 53 - 57.
54
410607100
Крышка
54
410608300
Porte Ampoule *holder-bulb
54
515176274
Лампа H4
58
414807200
Joint Torique *packing Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
60
515175343
Indicateur Ess.*gauge-fuel Formula 500 Deluxe. Formula Z 583. Formula 583 Deluxe.
9
515176548
Starter Switch, 3 Pos.
30
409210000
Электрическая клемма "папа"
49
391302100
Шайба
54
410609100
Phare *headlamp
54
515175911
Крышка
55
515176274
Лампа H4
56
515175911
Крышка
57
410608300
Porte Ampoule *holder-bulb
59
409210000
Электрическая клемма "папа"
